AHT - Atlantis

Atlantis is a Stan Tug 3011 - Fifi 1, with its excellent seakeeping behavior, the maneuverability the Atlantis has outstanding towing characteristics. The Atlantis has a bollard pull of 70 tonnes, classed by Bureau Veritas with an unrestricted sailing area.

The Atlantis is manned with an experienced crew, equipped with high quality gear and has a fully integrated Fire Fighting system. With its multi-purpose design and outstanding towing characteristics, the Atlantis can be used for worldwide operations such as, but not limited to, single and double towing, pushing, anchor handling, anchor recovery, rig move assistance, salvage assistance, wreck removal, harbor towage, escorting and deck and/or cargo transportation.

The Atlantis is heavily built with rigid foundations, extra plate thickness, extra brackets and extra fendering. The Atlantis is also equipped with a towing- and anchor handling winch, deck crane and Karmoy towing pins. Accommodation on board is provided for 10 persons.

Technical specifications Contact us

AHT ATLANTIS

VESSEL SPECIFICATIONS

Type AHT Damen Stantug
Classification Bureau Veritas Hull • Mach • AUT-UMS - Tug - Fire Fighting ship 1 - Water spraying / unrestricted
IMO number 9660932
Year built 2015 - Damen Song Cam, Vietnam
Flag Dutch
Port of registry Vlissingen
Call sign PBCI
MMSI 244850974
Length overall 30,66 m
Breath overall 11,13 m
Minimum draft 4,80 m
Operational Draft 5,10 m
Maximum draft 5,20 m
Minimum air draft 12,31 m
Maximum air draft 17,49 m
Gross tonnage 365 t
Net tonnage 109 t
System FIFI 1
Type Nijhuis pump type HGTF1-350.650
Capacity 2800 m³ / hr
Typel Heila HLM 0020-3S
Capacity 1,70t @ 10,00m
Fuel oil 166,0 m³
Fresh water 16,0 m³
Lubricating oil 1,5 m³
Hydraulic oil 1,5 m³
Dirty oil 2,9 m³
Sewage 4,7 m³
Bilge water 3,8 m³
Main engines 2x MTU 16V4000 M63R
Total power 3,680 KW / 4935bhp
Propulsion 2x fixed pitch propeller
Bowthruster 288 bhp, hydraulic
Main generator sets 2x CAT 6.6 TA
Fuel oil transfer pump 2x 20 m³ / hr
Fresh water transfer pump N/A
Fresh water maker HEM H25F3
Air compressor Atlas Copco LF7-10UV
Powerpack N/A
Free deckspace 73,0 m²
Deck strength 3,0 t/m²
Towing winch DMT Waterfall 80 t / 180 t (pull/hold) 800 m x 50 mm
Anchor Handling Winch 40 t / 180 t (pull/hold) 150 m x 50 mm
Tugger winch 2x Dromec 12 t
Towing pins Karmoy fork SWL 300t
Pushbow Full length rubber fendered - incl. towingbit SWL 40 t
Stern roller SWL 100t
Bollard pull 70 t
Maximum speed 13,00
Economic speed 8,00
Horsepower 4935
Persons 10
Single cabin 2
Double cabin 4
Air conditioned Yes

The information is for guidance purposes only and may be subject to changes.

PROVEN TRACK RECORD

The Atlantis has a proven track record and has worked all over the world. Contact our Commercial Department for any additional information you might need. Atlantis is ready to support your project anywhere in the world in a diverse working environment.
