SHOALBUSTER 3209 - SEA GOLF

Sea Golf is a Shoalbuster 3209 - FiFi 1, specially designed to work in shallow as well as in deeper waters with an unrestricted sailing area. The Sea Golf has a bollard pull of 50 tonnes, an operating draft of 3.00 meters and an increased stability with the combination of a large capacity of fuel oil and fresh water, perfect for diverse worldwide operations.

With its multi-purpose design, the Sea Golf can be used for a wide-ranging scope of work, covering, but not limited to, towing (single and double), pushing, dredging support, salvage assistance, wreck removal, harbor maintenance, harbor towage, escorting, buoy and anchor handling, anchor recovery, pipe and cable laying, deck and/or cargo transportation and pollution control in both inland and coastal waters.

The Sea Golf is manned with an experienced crew and equipped with the right quality gear for each job. The Sea Golf is equipped with a fully integrated Fire Fighting system, a heavy Heila deck crane, a towing- and anchor handling winch and a spacious aft deck. The work deck of the Sea Golf is equipped with towing pins, a karm fork and a wide stern roller. All to ensure the safety of the operations, whether towing or while performing anchor handling activities. Our vessels have a safe working environment for our crew.

Technical specifications Contact us

Shoalbuster 3209 SEA GOLF

VESSEL SPECIFICATIONS

Type Shoalbuster 3209
Classification Bureau Veritas • Hull • Mach • Unrestricted navigation / AUT-UMS - Tug - Fire Fighting ship 1 - Water spraying
IMO number 9901453
Year built 2020 - Damen Sharjah
Flag Dutch
Port of registry Vlissingen
Call sign PCSP
MMSI 244640000
Length overall 32,27 m
Breath overall 9,35 m
Minimum draft 2,90 m
Operational Draft 3,00 m
Maximum draft 3,20 m
Minimum air draft 10,30 m
Maximum air draft 16,85 m
Gross tonnage 335 t
Net tonnage 100 t
System FIFI 1
Type FFS
Capacity 2x 1400 m³ / hr
Typel Heila HLRM170-4SL
Capacity 7,9 t @ 15,93 m
Fuel oil 215,0 m³
Fresh water 40,0 m³
Lubricating oil 7,3 m³
Hydraulic oil 3,0 m³
Dirty oil 4,3 m³
Sewage 3,3 m³
Bilge water 4,3 m³
Main engines 2x CAT 3512C TTA/HD
Total power 2.610 kW / 3500 bhp
Propulsion 2x Promarin fixed pitch propellers
Bowthruster 350 bhp, hydraulic driven
Main generator sets 2x CAT C4.4 TA
Fuel oil transfer pump 50m³ /h @ 4.8 bar
Fresh water transfer pump 50m³ /h @ 4.8 bar
Fresh water maker N/A
Air compressor 1x ABAC 39m³ /h 11 bar
Powerpack 1x CAT C18 TA
Free deckspace 80,0 m²
Deck strength 5,0 t/m m²
Towing winch Kraaijeveld 50 t / 150 t (pull/hold) 800 m x 44 mm
Anchor Handling Winch 100 t / 150 t (pull/hold) 720 m x 44 mm
Tugger winch Dromec 12 t
Towing pins WK-Hydraulics SWL 50 t
Pushbow Full length rubber fendered
Stern roller SWL 100t
Bollard pull 49,8 t
Maximum speed 12,30
Economic speed 8,50
Horsepower 3600
Persons 11
Single cabin 1
Double cabin 5
Air conditioned Yes

The information is for guidance purposes only and may be subject to changes.

PROVEN TRACK RECORD

The Sea Golf has a proven track record and has worked all over the world in areas with limited maneuverability. Contact our Commercial Department for any additional information you might need. Sea Golf is ready to support your project anywhere in the world in a diverse working environment.
