SHOALBUSTER 2709 - SEA HOTEL

Sea Hotel is a Shoalbuster 2709, specially designed to work in shallow as well as in deeper waters with an unrestricted sailing area. The Sea Hotel has a bollard pull of 40 tonnes, an operating draft of 2.60 meters and an increased stability with the combination of a large capacity of fuel oil and fresh water, perfect for diverse worldwide operations.

With its multi-purpose design, the Sea Hotel can be used for a wide-ranging scope of work, covering, but not limited to, towing (single and double), pushing, dredging support, salvage assistance, wreck removal, harbor maintenance, harbor towage, escorting, buoy and anchor handling, anchor recovery, pipe and cable laying, deck and/or cargo transportation and pollution control in both inland and coastal waters.

The Sea Hotel is manned with an experienced crew and equipped with the right quality gear for each job. The Sea Hotel is equipped with a heavy Heila deck crane, a towing- and anchor handling winch and a spacious aft deck. The work deck of the Sea Hotel is equipped with towing pins, a karm fork and a wide stern roller. All to ensure the safety of the operations, whether towing or while performing anchor handling activities. Our vessels have a safe working environment for our crew.

Technical specifications Contact us

SHOALBUSTER 2709 SEA HOTEL

VESSEL SPECIFICATIONS

Type Shoalbuster 2709
Classification Bureau Veritas • Hull • Mach • / Unrestricted Navigation / AUT-UMS (SS)
IMO number 9695779
Year built 2013 - Damen Albwardy, UAE
Flag Dutch
Port of registry Vlissingen
Call sign PCWS
MMSI 244810135
Length overall 27,00 m
Breath overall 9,10 m
Minimum draft 2,20 m
Operational Draft 2,60 m
Maximum draft 2,85 m
Minimum air draft 8,50 m
Maximum air draft 15,20 m
Gross tonnage 221 t
Net tonnage 66 t
Typel Heila HLRM 0140-4SL
Capacity 5,30 t @ 18,00 m
Fuel oil 125,2 m³
Fresh water 30,0 m³
Lubricating oil 3,9 m³
Hydraulic oil 1,5 m³
Dirty oil 4,3 m³
Sewage 2,2 m³
Bilge water 4,3 m³
Main engines 2x CAT 3512 B
Total power 2.238 kW / 3040 bhp
Propulsion 2x Solid screw propeller Inox4, 362 rpm
Bowthruster 200 bhp, hydraulic driven
Main generator sets 2x CAT 4.4 TA
Fuel oil transfer pump 32 m³/h @ 1.5 bar
Fresh water transfer pump 32 m³/h @ 1.5 bar
Fresh water maker HEM 4,5 m³/24h
Air compressor 2x ABAC 2 times 19m³/h 9 bar
Powerpack 1x CAT C9 TA
Free deckspace 55,0 m²
Deck strength 2,0 t/m m²
Towing winch DMT Waterfall 50 t / 120 t (pull/hold) 600 m x 40 mm
Anchor Handling Winch 100 t / 120 t (pull/hold) 600 m x 40 mm
Tugger winch Promac 12 t
Towing pins S
Pushbow Full length rubber fendered
Stern roller SWL 50t
Bollard pull 40,3 t
Maximum speed 12,00
Economic speed 8,00
Horsepower 3040
Persons 7
Single cabin 3
Double cabin 2
Air conditioned Yes

The information is for guidance purposes only and may be subject to changes.

PROVEN TRACK RECORD

The Sea Hotel has a proven track record and has worked all over the world in areas with limited maneuverability. Contact our Commercial Department for any additional information you might need. Sea Hotel is ready to support your project anywhere in the world in a diverse working environment.
